Old narrow gauge Steam loco, Aljustrel. 13-07-2002

©Sérgio Miguel Parreira [smparreira@yahoo.com]



Old narrow gauge Steam loco, Aljustrel. 13-07-2002

©Sérgio Miguel Parreira [smparreira@yahoo.com]



Old narrow gauge Steam loco, Aljustrel. 13-07-2002

©Sérgio Miguel Parreira [smparreira@yahoo.com]



CP - Portugal
Narrow gauge railway museum in Lousado (near Porto).
Locomotive number 6 of the narrow gauge Caminhos de Ferro de Guimaraes was built in 1907 in Esslingen in Germany. In 1947 CP took over the locomotive (new number E 101) and used it on the Vouga narrow gauge system. It was withdrawn from active service in 1977.

Lousado, 17-10-2017

Digital photo by Marco van Uden




CP - Portugal
Narrow gauge steam locomotive E166 (069166) stored in the station of Tua. The narrow gauge line to Bracanga has been closed, apart from the Cachao-Mirandela-Carvalhais "Mirandela Metro".
Tua, 17-11-2011

Digital photo by Marco van Uden




CP - Portugal
What remains of narrow gauge steam locomotive MD213 (079213) in Pocinho is not much. It is very likely that it will never run again. The narrow gauge line from Pocinho was already closed many years ago.
Pocinho, 17-11-2011

Digital photo by Marco van Uden




CP - Portugal
What remains of narrow gauge steam locomotive MD213 (079213) in Pocinho is not much. It is very likely that it will never run again. The narrow gauge line from Pocinho was already closed many years ago.
Pocinho, 17-11-2011

Digital photo by Marco van Uden




CP - Portugal
Narrow gauge steam locomotive E170 stabled in Tua. This locomotive really could use some paint.
Tua, 17-11-2011

Digital photo by Marco van Uden




Locomotiva a vapor CP E97 na estação da Trofa, Dezembro de 1996. CP E97 steam locomotive in Trofa railway station, December 1996.

Photo and scan by David Neves (davidnukem@hotmail.com)




The last special steam train organize by APAC. Narrow Gauge Steam Locomotive n: E97.

Photo by Pedro Milheiro
Scan by Pedro Costa




Vale do Vouga nº 313 junto ao museu de Mancinhata. Era um dia chuvoso... Vale do Vouga nº 313 near museum of Mancinhata. That was a raining day...

Photo: Pedro Costa Http://comboiosdonorte.fotopic.net




E1 em exposição na Régua. 2006 E1 static at Régua. 2006

Photo: Pedro Costa (ComboiosdoNorte)




Over twenty years ago SBB was asked to name a locomotive « Franches-Montagnes ». In relation with the 100th horse market in Saignelégier SBB decided to name Re 460 036-7 « Franches-Montagnes » on the 8th of august 2003 in this narrow gauge station of Chemins de fer du Jura. It is 25 kilometres away from the next standard gauge station. On the 7th of august the locomotive arrived in Glovelier and was charged on two trucks and pulled by steam traction to Saignelégier. Between Combe-Tabeillon and Bollement there are eight tunnels, which have a reduced height of contact wire. For security the SBB-locomotive was pulled by steam traction. At no time the loco was in contact with the overhead wire. After the naming ceremony the locomotive was exhibited in Saignelégier station till Monday and then brought back to Glovelier by an electric engine. It is the first time that a locomotive of the type Re 460 stays on a metric gauge station. Other transports of this kind have been done by road for special events, but never by rail.
The steam locomotive E 164 was delivered in 1905 by Henschel in Cassel to Portugal. Today this factory is absorbed by the Bombardier group. In 1993 the steam engine was brought back to Switzerland in 1993 by La Traction. It entered service in 1999 after a general overhaul in Meiningen on the metric network of Chemins de fer du Jura.
The SBB Re 460 036-7 was built by SLM and ABB in Winterthur and Zurich and delivered in 1993. Both works haven been taken over by the Bombardier group. Today there are no more factories, but engineering sites. It is one of the few locomotives which have not been named till today and which spot no advertising livery.

Photo by Théo Stolz <theo.stolz@cj-transports.ch>




Over twenty years ago SBB was asked to name a locomotive « Franches-Montagnes ». In relation with the 100th horse market in Saignelégier SBB decided to name Re 460 036-7 « Franches-Montagnes » on the 8th of august 2003 in this narrow gauge station of Chemins de fer du Jura. It is 25 kilometres away from the next standard gauge station. On the 7th of august the locomotive arrived in Glovelier and was charged on two trucks and pulled by steam traction to Saignelégier. Between Combe-Tabeillon and Bollement there are eight tunnels, which have a reduced height of contact wire. For security the SBB-locomotive was pulled by steam traction. At no time the loco was in contact with the overhead wire. After the naming ceremony the locomotive was exhibited in Saignelégier station till Monday and then brought back to Glovelier by an electric engine. It is the first time that a locomotive of the type Re 460 stays on a metric gauge station. Other transports of this kind have been done by road for special events, but never by rail.
The steam locomotive E 164 was delivered in 1905 by Henschel in Cassel to Portugal. Today this factory is absorbed by the Bombardier group. In 1993 the steam engine was brought back to Switzerland in 1993 by La Traction. It entered service in 1999 after a general overhaul in Meiningen on the metric network of Chemins de fer du Jura.
The SBB Re 460 036-7 was built by SLM and ABB in Winterthur and Zurich and delivered in 1993. Both works haven been taken over by the Bombardier group. Today there are no more factories, but engineering sites. It is one of the few locomotives which have not been named till today and which spot no advertising livery.

Photo by Théo Stolz <theo.stolz@cj-transports.ch>




CP - Portugal
Narrow gauge railway museum in Lousado (near Porto).
Locomotive Norte 104 was one of the most powerful narrow gauge locomotives on the Iberic peninsula. It was built in 1931 by Henschel in Germany and mainly used for express passenger trains from Porto to Guimaraes and Povoa, until replacement diesel trains took over in 1977.

Lousado, 17-10-2017

Digital photo by Marco van Uden




CP - Portugal
Narrow gauge railway museum in Lousado (near Porto).
Locomotive PPF 14 of the Caminhos de Ferro de Porto a Povoa e Famalicao was built in 1905 by Henschel in Germany. It later became E 151 of CP and was in the end used as spare diesel motor cars on the Tamega line (Douro Valley). The locomotive was withdrawn from active service in 1977/1978.

Lousado, 17-10-2017

Digital photo by Marco van Uden




CP - Portugal
Narrow gauge railway museum in Lousado (near Porto).
Locomotive PPF 6 of the Caminhos de Ferro de Porto a Povoa e Famalicao was built in 1874 by Black Hawthorn in England. It was originally built for 900mm gauge and later regauged to meter gauge. The locomotive was withdrawn from service in 1944.

Lousado, 17-10-2017

Digital photo by Marco van Uden




Estação do Pocinho. Terminus da linha do Douro.
Antiga locomotiva da linha do Sabor.

Pocinho station. Douro line terminus.
Old locomotive of Sabor line.

19-04-2006, Jose Sousa, jm-ss@netcabo.pt




Estação da Régua.
Linha do Douro [1668mm via larga] e do Corgo [1000mm via estreita] (entre Régua e Vila Real).
Antiga locomotiva da linha do Corgo.

Régua station.
Douro line [1668mm large gauge] and Corgo line [1000mm narrow gauge] (between Régua and Vila Real).
Old locomotive of Corgo line.

19-04-2006, Jose Sousa, jm-ss@netcabo.pt




Estação da Régua.
Linha do Douro [1668mm via larga] e do Corgo [1000mm via estreita] (entre Régua e Vila Real).
Antigo material das duas linhas.

Régua station.
Douro line [1668mm large gauge] and Corgo line [1000mm narrow gauge] (between Régua and Vila Real).
Old material of two lines.

19-04-2006, Jose Sousa, jm-ss@netcabo.pt




Estação da Régua.
Linha do Douro [1668mm via larga] e do Corgo [1000mm via estreita] (entre Régua e Vila Real).
Antigo material da linha do Corgo.

Régua station.
Douro line [1668mm large gauge] and Corgo line [1000mm narrow gauge] (between Régua and Vila Real).
Old material of Corgo line.

19-04-2006, Jose Sousa, jm-ss@netcabo.pt




A steam loco somewhere in Portugal (I don't remember where exactly...). 1989.

Photo : Durvaux Christophe (tofdurvaux@netcourrier.com)




Estação do Tua.
Linha do Douro [1668mm via larga] e do Tua [1000mm via estreita] (entre Tua e Mirandela).
Antigo comboio da linha do Tua.

Tua station.
Douro line [1668mm large gauge] and Tua line [1000mm narrow gauge] (between Tua and Mirandela).
Old train of Tua line.

19-04-2006, Jose Sousa, jm-ss@netcabo.pt




One of the last steam trains in Portugal, in Tamega line, at Livracao, one Mallet.

Photo and scan by Pedro Costa <pmcosta@ip.pt>




Subject: narrow gauge B'Bt Mallet locomotive E166 standing aside
Location: Tua - Portugal
Date: june1995

Photo: Ernst Kers <ernst.kers@pi.net>




Regua (Portugal), august 1997. Narrow gauge steamlocomotive E1 mounted as monument.

Photo and scan by Ernst Kers <ernst.kers@pi.net>




Regua (Portugal), august 1997. Nine narrow gauge 1B'Ct Mallet steamlocomotives waiting for their fate. Henschel constructed in 1911-1923 eighteen locomotives of this type for the Portugese railways.

Photo and scan by Ernst Kers <ernst.kers@pi.net>




Subject: B'Bt narrow gauge Mallet locomotive preserved and with the ancient number MD 405
Location: Lousado - Portugal
Date: october 1993

Photo: Ernst Kers <ernst.kers@pi.net>
This locomotive origins from the Minho-Douro and belongs to a series constructed by Henschel in 1905-09. With the CP they were numbered E161-170.




Subject: 1B'Ct narrow gauge Mallet locomotive preserved and with the ancient number MD 464
Location: Lousado - Portugal
Date: october 1993

Photo: Ernst Kers <ernst.kers@pi.net>
This locomotive origins from the Minho-Douro. The CP owned 18 locomotives of this type. 16 came from the MD (E201-216) and 2 from the Norte (E181-182).They were constructed by Henschel in 1911-23.




Freight car with remains of machinery and steam loc MD 213 of narrow gauge line(closed) from Pochinho to Miranda do douro (Portugal)aug.2003.

Photo and scan prossum@mail.hzeeland.nl




Steam loc 213 at of abandoned narrow guge line at railway station of Pochinho (Portugal)aug.2003.

Photo and scan prossum@mail.hzeeland.nl




Subject: 1B'Ct narrow gauge Mallet locomotive preserved and with the ancient number PPF 41
Location: Lousado - Portugal
Date: october 1993

Photo: Ernst Kers <ernst.kers@pi.net>
This locomotive origins from the Porto - Povoa de Varzim line and was owned by the "Norte".




Preserved Norte 103 narrow gauge 2-8-2T built by Henschel in 1908 at Boavista staion, Oporto 19 June 1990.

Photo and scan copyright Pat & David Othen, Dartmouth, Nova Scotia, Canada (dothen@ra.isisnet.com)




E1 - narrow gauge0-4-0T built by Henschel & Sohn in 1922 sits outside Regua station, in apparent operating condition,18 June 1990.

Photo and scan copyright Pat & David Othen, Dartmouth, Nova Scotia, Canada (dothen@ra.isisnet.com)




Eleven narrow gauges Malletts were sitting forlornly around this dual gauge turntable at Regua station, 18 June 1990.

Photo and scan copyright Pat & David Othen, Dartmouth, Nova Scotia, Canada (dothen@ra.isisnet.com)




Subject: 2'Ct narrow gauge locomotive while preservation was in progress and with the ancient number VV 12
Location: Lousado - Portugal
Date: october 1993

Photo: Ernst Kers <ernst.kers@pi.net>
This locomotive origins from the Val do Vouga. The CP owned 4 locomotives (E121-124) of this type. They were constructed by Borsig in 1908.




CP E168, Henschel Mallet locomotive built 1908, 2008 bought from Portugal, Brohl, 2017-08-27.

tobias b köhler
