Diesel-electric locomotive D20E-001 of Vietnam Railways (VNR or DSVN).
Built by Siemens (type AsiaRunner AR15VR), a six axle metre gauge
adaptation of the ER20 (ÖBB 2016). D20E means: Diesel locomotive,
2000 horsepower, Electric transmission.
Wheel arrangement Co'Co', gauge 1000 mm, mass 81 t, length 19180 mm, width 2820 mm including mirrors, height 3945 mm, bogie distance 10300 mm, axle distance in bogie 1650 mm, wheel diameter 1016 mm, maximum speed 120 km/h, diesel engine MTU 12V 4000 R41, power 1500 kW, rotational speed 600 to 1800 per minute, tractive effort 260 kN at departure, 234 kN constantly at 19 km/h, electric braking force 150 kN, operational temperature range +5°C to +55°C. 20 units were delivered from 2006. The other modern locomotive is the Chinese designed D19E which is partly assembled in the Gia Lam workshops in Vietnam (80 locomotives are ordered/delivered); it seems that for further orders the Chinese design is currently favoured (does the same job, but cheaper than Siemens?) The D19E and D20E are currently the most modern and powerful locomotives in Vietnam (though compared to what would be possible on standard gauge, they are only medium power). The track and signalling systems don't allow any speeds higher than 120 km/h and it seems that most sections are much slower. InnoTrans September 2006, Berlin. |
|
Diesel-electric locomotive D20E-001 of Vietnam Railways (VNR or DSVN).
The livery in dark turquoise and white is unique to this class, not
matching anything else on Vietnam Railways. It seems they are making up
new colours with each new locomotive class.
Siemens intended to offer this locomotive class to other railways of the
region, such as Thailand or Malaysia, but until now there have not been
any further orders. However the electric system (generator, inverters,
traction motors) was also used in the RhB Gmf 4/4 II locomotives built
2013 by Schalker Eisenhütte.
InnoTrans September 2006, Berlin. |
|
Diesel-electric locomotive D20E-001 of Vietnam Railways (VNR or DSVN).
One person in a white shirt is highly interested in the bogie as it
seems ...
InnoTrans September 2006, Berlin. |
|
Diesel-electric locomotive D20E-001 of Vietnam Railways (VNR or DSVN).
View on the VNR = Duong Sat Viet Nam logo, and the 4000 liter tank.
InnoTrans September 2006, Berlin. |
| D20E-001 coming into Hue station with train SE2 (Sai Gon - Ha Noi). One of the sleeping coaches in a different livery is labeled "Livitrans Express" and offers service by a private company. 2014-05-09. |
| D20E-001 coming into Hue station with train SE2 (Sai Gon - Ha Noi). This locomotive was built 2006 as the first of 16 Asiarunner AR15VR locomotives by Siemens; I had first visited it when it was shown on the InnoTrans that year - see my other Photos in this directory. Length 19180 mm, 1500 kW, 120 km/h. 2014-05-09. |
|
Diesel-electric locomotive D20E-001 of Vietnam Railways (VNR or DSVN).
Interior of the engine room. Of course it is narrow, being a metre gauge
locomotive, so not much space for the side corridor.
InnoTrans September 2006, Berlin. |
|
Diesel-electric locomotive D20E-001 of Vietnam Railways (VNR or DSVN).
Driver's desk with analog instruments and diagnosis flatscreen.
InnoTrans September 2006, Berlin. |
| D20E-004 in Da Nang station where all trains reverse direction and the locomotive is changed. 2014-05-05. |
| D20E-004 in Da Nang station where all trains reverse direction and the locomotive is changed. 2014-05-05. |
| The Diesel locomotive D20E-015 has just been coupled in front of train SE4 (Sai Gon - Ha Noi) in Da Nang station. 2014-05-05. |
| A closer look on the D20E-015 in Da Nang. 2014-05-05. |
| Train SE4 (Sai Gon - Ha Noi) pulled by the D20E-016 on the most scenic section of the line, the coastal section between Da Nang and Hue. 2014-05-07. |
| The Diesel locomotive D20E-016 has just been coupled in front of train SE4 (Sai Gon - Ha Noi) in Da Nang station. This is the last built Asiarunner, Siemens probably hoped to sell similar types to other countries but has not yet received any such order. 2014-05-07. |
|
Locswitch at Dieu Tri between Nha Trang and Danang on 23 february 2008
Photo by Drikus van Uchelen from the Netherlands. e-mail: mr.h.l.vanuchelen@vanuchelen.com |
|
D20E-003 (Siemens AR15VR).
Engine in Danang Station, february 2008.
Photo by Drikus van Uchelen, Zeewolde, the Netherlands mr.h.l.vanuchelen@vanuchelen.com |
|
D20E-003 (Siemens AR15VR).
Danang Station, 23 february 2008.
Photo by Drikus van Uchelen from the Netherlands. e-mail: mr.h.l.vanuchelen@vanuchelen.com |
|
Danang Station, 23 february 2008.
Photo by Drikus van Uchelen from the Netherlands. e-mail: mr.h.l.vanuchelen@vanuchelen.com |
|
Danang Station, 23 february 2008.
Photo by Drikus van Uchelen from the Netherlands. e-mail: mr.h.l.vanuchelen@vanuchelen.com |
|
Waiting engines at Dieu Tri
between Nha Trang and Danang on 23 february 2008.
The D11H-348 was built in Romania, part of a series delivered 1978 to
1980. They are similar to narrow gauge locomotives in Bulgaria.
Photo by Drikus van Uchelen from the Netherlands. e-mail: mr.h.l.vanuchelen@vanuchelen.com |
