Old line: 1956 Station sign. The round stone wall is part or Rainer's Royal Palace. Open to public is the white building, the oceanographic museum, as well as the wonderful Saint-Martin Park with its pine trees hanging over the edge of the cliff.



Nov.28, 1999 (C) Kristian Hasenjager



Old line: Platform seats of 1956 station, 25kV overhead line insulators.



Nov.28, 1999 (C) Kristian Hasenjager



Old line: Monegasque (correct?) people inspect their new western station entrance. Despite its entrance with triumphant columns and its false balustrade, the ensemble fits pretty well into the old wall. Switchover to the new 2.8km long tunnel took place during the previous night.



Nov.28, 1999 (C) Kristian Hasenjager



Old line: Behind the automatic sliding doors, a 300 meter long tunnels leads to the main station hall. The tunnels is outfitted with expensive polished stone, it looks more like Galeries Lafayette than a SNCF tunnel. Monaco people use the conveyor belts to silently reach the platforms, supervised by at least half a dozen CCTV cameras. The tunnel will be clinically clean in 20 years as well. All tunnel works have been financed by Monaco, but executed by SNCF groups.



Nov.28, 1999 (C) Kristian Hasenjager



New line: A snapshot half a year earlier from inside a first class SBB panoramic coach, just in the moment it crosses the 1956 bridge shown in the previous image. This previous image is taken from the roof of the station complex, in the upmost part of the image.
The wide lower arch, embracing its glass front is the main east entrance of the new station tunnel. Above lies a small park, and behind all deep in the rocks emerges a 13 storey car park. Station access is from roads above the picture as well, using a system of escalators and fast lifts.
Notice the high window of the fine swiss (zebra) coach on his way from Nice to Milan and Zürich in july 1999.



July, 1999 (C) Kristian Hasenjager



New line: Main councourse hall, the wide arch squeezed inside the narrow valley. Wide spacious surfaces. Outside the 1956 tunnel mouth.



Nov.28, 1999 (C) Kristian Hasenjager



New line: Curbed alignment of the 465 meter long station. Invisible at its end, the 300 meter western access tunnel. The 24 meter wide naked concrete hall spans 3 tracks with two platforms. The lower part of the tunnel walls are fitted out with arrays of simple unpainted slats to avoid the typical metrostation echo. Together with halogene type lighting, a pretty warm atmospheres embraces the passengers waiting for the TER to from italian Ventimiglia towards Nice.



Nov.28, 1999 (C) Kristian Hasenjager



New line: Escalators to mezzanine wooden level, leading to ticket offices, car park and upper exit. The mezzanine floor is made like a deck of a ship, reminding the proximity of the mediterranean sea. The rectangular concrete pylon intercepts the weight of another high pylon outside above of it.



No freight trains are allowed inside the 2.8km tunnel at the same time with passenger trains. Both ends of the station can be shielded by curtains of water in case of toxic gas or fire accidents. The whole tunnel system, not only the station itself, is equipped with powerful sprinkler extinguishers. An additional emergency tunnel enables road vehicle access to the station.



Nov.28, 1999 (C) Kristian Hasenjager



New line: Behind the mezzanine deck, the yellow departure and the white arrival screens. New station furniture is very well designed by SNCF nowadays. The main tunnel bites into the mountain on the right, while the wide arch escapes towards the sea.



Nov.28, 1999 (C) Kristian Hasenjager



New line: Just below street level, under the upmost arch some of dozen meters above rail level. The interior shielded by the wide windows has its roof formed by a span of an existing (stone) road bridge evidenced by indirect lighting. Approximately five parallel lifts give access to the 13 car parking decks and to the station mezzanine, while escalators finally lead to the surface of this three dimensional wonderland.



Nov.28, 1999 (C) Kristian Hasenjager



SNCF (French Railways)
Monaco Monte Carlo,  17.5.2003

Photo: Darko Pahic Szabo - more photos on http://www.vlaki.com




SNCF (French Railways)
Monaco Monte Carlo,  17.5.2003

Photo: Darko Pahic Szabo - more photos on http://www.vlaki.com




SNCF (French Railways)
Monaco Monte Carlo,  17.5.2003

Photo: Darko Pahic Szabo - more photos on http://www.vlaki.com




SNCF (French Railways)
Monaco Monte Carlo,  17.5.2003

Photo: Darko Pahic Szabo - more photos on http://www.vlaki.com




SNCF (French Railways)
Monaco Monte Carlo,  17.5.2003

Photo: Darko Pahic Szabo - more photos on http://www.vlaki.com




SNCF (French Railways)
Monaco Monte Carlo,  17.5.2003

Photo: Darko Pahic Szabo - more photos on http://www.vlaki.com




Monaco-Monte Carlo station.

Photo by Emanuele Rava, 17-9-2008 e-mail emanrava@yahoo.it




Monaco-Monte Carlo station.

Photo by Emanuele Rava, 27-12-2009 e-mail emanrava@yahoo.it




Monaco-Monte Carlo station.

Photo by Emanuele Rava, 27-12-2009 e-mail emanrava@yahoo.it




Montecarlo 2006 mai 30 - Rien ne va plus dans l'aire des vieille gare. Mais j'imagine de voir encore passer le TEE "Ligure"... comme un fantôme...

Photo de Alfredo Grasso <alfre.g@tiscali.it>




The new station MONACO-MONTE-CARLO on the railway line Nice-Ville - Ventimiglia (Côte d'Azur) is in underground.

Photo and scan: Slobodan Ilic, 20.07.2001 (slobodan.ilic@bluewin.ch)




La gare de Monaco depuis la cabine de la Zx 24502 (présentation des nouveaux TER 2N NG)
Monaco, Mercredi 3 mars 2004

Photo : Jean-Paul Lescat (lescatj-p@azur.fr)




The station of Monaco Monte-Carlo (1)

Here you can see the interior of the Monaco-Monte-Carlo station , opened in 2000 , looking towards Nice.

Monaco-Monte-Carlo , 27/07/2004

Photo by : Denis Verheyden Visit www.nmbsforum.be for train discutions.




The station of Monaco Monte-Carlo (2)

Here you can see the interior of the Monaco-Monte-Carlo station , opened in 2000 , looking towards Ventimiglia (I).

Monaco-Monte-Carlo , 27/07/2004

Photo by : Denis Verheyden Visit www.nmbsforum.be for train discutions.
