ATGV, project of an aerodynamically improved TGV, power car together with a middle car turned the wrong way (half Jacobs bogie towards the power car??) shown at the pavillion of France at the Expo 2000, Hannover.

Photo: tobias b köhler


TGV 9864 (Nice Ville-->Bruxelles Midi/Brussel Zuid), seen at Tuileries Jct, where the Marseilles-Paris HSL branches off the conventional line.
This formation features:

a TGV Réseau (Tri-voltage) set, at the rear, running from Nice to Brussels, and
a TGV Duplex set (Dual-voltage) set, at the front, diagrammed as a matter of relief on Marseilles-Lille.
At this stage, this formation is already running on the HSL ("Up" track), with all pantographs down, owing to the voltage change-over (1.5kV DC--->25kV-50Hz AC).
The front half of the Duplex set is already running under 25kV.
This formation is about to enter the Marseilles HSL tunnel, currently the largest French domestic railway tunnel (7,836m).

This TGV service holds a 3-fold absolute record, as it is:

the most veteran Brussels-French Regions TGV service, introduced on 28th May 1995;
the largest-distance TGV service, with 1,287km-800mi throughout;
the service which uninterruptedly cumulates the highest HSL mileage in Europe, with 1,046km-650mi of HSL from Tuileries Jct here until Lembeek (Belgium), not even switching to conventional tracks on Grenay-Sathonay to call at Lyon-Part Dieu.

Marseilles (Tuileries Jct).
29th January 2005.

P.L.Guillemin (plguillemin@yahoo.fr)


Paris Gare du Nord
TGV-Réseau 509
Thalys PBA 4532
2004.06.07, 10h51

Photo by Rafal Tomasik, www page : http://www.tgv.w.pl


Paris Gare du Nord
TGV-Réseau 509
Thalys PBA 4532
Thalys PBKA 4321
2004.06.07, 10h54

Photo by Rafal Tomasik, www page : http://www.tgv.w.pl


Paris Gare du Nord
TGV-Paris Sud-Est
TGV-Réseau 509
2004.06.07, 10h56

Photo by Rafal Tomasik, www page : http://www.tgv.w.pl


Paris Gare du Nord
TGV-Paris Sud-Est 71
Thalys PBA 4435
Thalys PBKA 4306
2004.06.15, 10h24

Photo by Rafal Tomasik, www page : http://www.tgv.w.pl


Paris Gare du Nord
TGV-Paris Sud-Est 89
TGV-Réseau 522
Thalys PBKA 4342
Thalys PBKA 4304
THA9429 Paris Nord - Köln-Deutz
Thalys PBKA 4302
2004.08.19, 11h44

Photo by Rafal Tomasik, www page : http://www.tgv.w.pl


Late-night TGV in the Burgundy landscape passing a road bridge near the village of St Ythaire (about 20 km north of Cluny, departement 71). 1 second exposure. 28 July 2005
Photo by Bill Harrison (bill.harrison@dsl.pipex.com)


TGV's at Paris Gare de Lyon in August 1997
Photo and scan D.P.szabo (dp.szabo@ibm.net)


Some cool TGV at Paris Gare du Nord.
A Thalys PBKA (Paris Brussels Köln Amsterdam),
3 TGV-R and a Thalys PBA (Paris Brussels Amsterdam).
September, 1997.

Photo and scan: Stefano Bertolotti (gundam@iol.it)


Some cool TGV at Paris Gare du Nord.
A Thalys PBKA (Paris Brussels Köln Amsterdam),
3 TGV-R and a Thalys PBA (Paris Brussels Amsterdam), and in background an Eurostar.
September, 1997.

Photo and scan: Stefano Bertolotti (gundam@iol.it)


Paris Gare du Nord
TGV-Réseau 541
Thalys PBKA 4301
and Thalys PBA 4535
2002.10.24, 16h20

Digital photo by Rafal Tomasik WWW page


gare de triage de nice riquier
photo de tgv
Photo prise par Loic Beraud cityliner@caramail.com


gare de triage de nice riquier
photo de tgv
Photo prise par Loic Beraud cityliner@caramail.com


gare de triage de nice riquier
photo detail de tgv de nuit
Photo prise par Loic Beraud cityliner@caramail.com


gare de triage de nice riquier
photo detail de tgv de nuit
Photo prise par Loic Beraud cityliner@caramail.com


gare de triage de nice riquier
photo detail de tgv de nuit
Photo prise par Loic Beraud cityliner@caramail.com


gare de triage de nice riquier
photo detail de tgv de nuit
Photo prise par Loic Beraud cityliner@caramail.com


gare de triage de nice riquier
photo de tgv de nuit
Photo prise par Loic Beraud cityliner@caramail.com


gare de triage de nice riquier
photo de tgv de nuit
Photo prise par Loic Beraud cityliner@caramail.com


gare de triage de nice riquier
photo de tgv de nuit
