Renfe: 120 Nueva serie 120 realizando pruebas entre Castellon y Tarragona. New series 120 carrying out tests between Castellon and Tarragona. Station: Las Palmas (Castellon) - 14/02/2005 Photo: Carlos Pérez Arnau carlosperez@studio3.es


Renfe: 120 Nueva serie 120 realizando pruebas entre Castellon y Tarragona. New series 120 carrying out tests between Castellon and Tarragona. Station: Las Palmas (Castellon) - 14/02/2005 Photo: Carlos Pérez Arnau carlosperez@studio3.es


AVE-120 001 set, seen on trials at Burgos. Burgos. 10th August 2004. Photo by José Ramón Ampudia (jotaerre@tranvia.org) (Acknowledgements). Posting and comment by P.L.Guillemin (plguillemin@yahoo.fr).


Variable-gauge bogie of AVE-120 001 set. This bogie is based upon the BRAVA system developed by CAF. As on RD system of Talgo (and unlike SUW2000 of PKP), wheels are unloaded when changing gauges, hence these little shoes which slide on supporting rails. Photo by Diego Roque (bpt@tranvia.org) (Acknowledgements), from Tranvia.org Posting and comment by P.L.Guillemin (plguillemin@yahoo.fr)


Clearance data, seen down carbodies of AVE-120.001 set. One can notice that these fleet is to run Spain only, as there is no gauge-changer compatible with CAF-BRAVA on the French border, and while even with standard-gauge throughout, these sets may not fit in the UIC loading-gauge... They won't be able to run in Portugal, either, at least not until Medina del Campo-Villar Formoso has been wired up. One can also see that these sets are classified as 250N. This is to apply only to HSLs. On conventional lines (3kV), these sets will be cleared as 220A, as AVE-101s (Euromed). Photo by Diego Roque (bpt@tranvia.org) (Acknowledgements). Posting and comment by P.L.Guillemin (plguillemin@yahoo.fr)


Scharffenberg coupler of AVE-120.001 set. Photo by Diego Roque (bpt@tranvia.org) (Acknowledgements). Posting and comment by P.L.Guillemin (plguillemin@yahoo.fr)


Electrotrén 120.002 camino del puerto de Pajares para hacer pruebas. Venta de Baños, 09 de Marzo de 2005. Foto: JGC -//- e-mail: Jorge_ut440@ut440.com -//- Web: http://www.ut440.com


120.003 estacionado en el depósito de Cerro Negro. Cerro Negro (Madrid), 05 de Junio de 2005. Foto: JGC -//- e-mail: Jorge_ut440@ut440.com -//- Web: http://www.ut440.com
