Formsignale im Bahnhof Goslar
31.Januar 2015

Photo: Christian Immler - fotos@christianimmler.de - www.christianimmler.de
Kamera: Samsung Galaxy S4 Zoom (SM-C101)




Formsignale im Bahnhof Goslar
31.Januar 2015

Photo: Christian Immler - fotos@christianimmler.de - www.christianimmler.de
Kamera: Samsung Galaxy S4 Zoom (SM-C101)




Small semaphore in Dresden Neustadt.

Photo (September 2002): Janne Petersson (e-mail: petersson_janne@hotmail.com)




Semaphore at Sassnitz station.

Photo (october 2004): Janne Petersson (e-mail: petersson_janne@hotmail.com)




Signals at Diessen station. 15 july 1992

Photo: Yuri van Laarhoven (yuri.vanlaarhoven@wanadoo.nl)




Signals at Diessen station. 15 july 1992

Photo: Yuri van Laarhoven (yuri.vanlaarhoven@wanadoo.nl)




Sigmaringen station.

Photo by Emanuele Rava, 21-8-2013 e-mail emanrava@yahoo.it




Formsignale in Wörth (Pfalz)
Ausfahrt einer Straßenbahn Richtung Karlsruhe

Foto: Michael Kauffmann
größer




Signalling in Germany: exit formsignals in Chemnitz Hbf in direction to Dresden. Date: August 2011.

Digital photo by Zoltan Czifra




Gleisfeld Bremen Hbf, Anfang der 1980er.

Photo by Ulrich Behning (ubehning@freenet.de)




In Linnich, the end of the DKB line is marked by a semaphore in a permanent "halt" position. Some freight wagons are stored on the rest of the track, then soon there's nothing more. There once was a line towards Baal - Ratheim - Dalheim, but it has been removed. There are discussions about reactivation but no plans for the immediate future. 2010-06-07.

tobias b köhler




Approaching Lindau Hbf coming from Kempten im Allgau.

Photo: Emanuele Rava, 03-05-08 e-mail: emanrava@yahoo.it




The station of Norddeich seen from the platform end of Norddeich Mole. Only a road crossing is separating the two stations.

Photo by Johan van den Akker (e-mail:vdakker@acm.org)




DB Mechanical Signal.
Signal at Halberstadt Bahnhof photographed on Wednesday May 7th, 2003.

Photo by Michael Taylor, Hamilton, Ontario, Canada. (michael@einbahn.org)

Website www.EinBahn.org




Die Seil züge fpr Die Signalen von Oberhausen Osterfeld

Foto Vincenzo M enzo8@gmx.de 12.6.2006




18 April 2003 (Good Friday), freight yard: Karlsruhe Gbf, Germany
Mechanical main and approach signal, each capable of showing three aspects; in the background a DB Cargo class 294 shunter in verkehrsrot livery

18. April 2003 (Karfreitag), Bf. Karlsruhe Gbf, Deutschland
Form-Haupt- und Vorsignal, jeweils dreibegriffig; im Hintergrund eine DB-Cargo-Rangierlok der Baureihe 294 in Verkehrsrot

Photo by Sven Manias (sven.manias@gmx.de)




Historical track equipment, Sinsheim (Elsenz) Hbf
Semaphore signals 'Hp 0' and 'Vr 0', clamping and milestones in front of the engine shed of the railway friends Kraichgau at Sinsheim. 628 437 behind. Photo taken Sunday 17 August 2014.

Photo: Steffen Mokosch (Steffen.Mokosch@web.de)




Bahnhof Calau (Niederlausitz)

Formsignale, aufgenommen am 16. Juni 2010.

Photo: Claudia Kittendorf-Wolf (info@claudia-blondie-wolf.de)
Homepage: www.claudia-blondie-wolf.de




Bahnhof Chemnitz HBF

Formsignal in Chemnitz Hauptbahnhof am 11. Mai 2006.

Photo: Claudia Wolf (info@claudia-blondie-wolf.de)
Homepage: www.claudia-blondie-wolf.de




Bahnhof Coburg - Signale

Formsignale für die Ausfahrt aus dem Bahnhof von Coburg. (21. Juni 2003)

Photo: Bernd Kittendorf (info@bernd-kittendorf.de)
Homepage: www.bernd-kittendorf.de




Bahnhof Gera Hauptbahnhof

Formsignale im Bahnhof Gera HBF während umfangreicher Gleisbauarbeiten. (09. August 2004)

Photo: Bernd Kittendorf (info@bernd-kittendorf.de)
Homepage: www.bernd-kittendorf.de




Bahnhof Offenburg

Vorsignal an der Einfahrt in das Rangiergelände des Bahnhofs Offenburg von Norden kommend am 15. April 2006.

Photo: Bernd Kittendorf (info@bernd-kittendorf.de)
Homepage: www.bernd-kittendorf.de




Bahnhof Offenburg

Einfahrt in das Rangiergelände des Bahnhofs Offenburg von Norden kommend am 15. April 2006.

Photo: Bernd Kittendorf (info@bernd-kittendorf.de)
Homepage: www.bernd-kittendorf.de




Bahnhof Sinsheim (Elsenz)

Stellwerksgebäude und Formsignale im Bahnhof Sinsheim (Elsenz), aufgenommen am 29. September 2007.

Photo: Bernd Kittendorf (info@bernd-kittendorf.de)
Homepage: www.bernd-kittendorf.de




Bahnhof Sondershausen

Formsignal im Bahnhof von Sondershausen (Fahrtrichtung Nordhausen). (12. August 2004)

Photo: Bernd Kittendorf (info@bernd-kittendorf.de)
Homepage: www.bernd-kittendorf.de




Bahnhof Sondershausen

Formsignal im Bahnhof von Sondershausen (Fahrtrichtung Nordhausen). (12. August 2004)

Photo: Bernd Kittendorf (info@bernd-kittendorf.de)
Homepage: www.bernd-kittendorf.de




Bahnhof Wiesbaden Igstadt

Auch am 26. März 2005 wurden in Wiesbaden Igstadt noch mechanische Signale verwendet. Hier die Ausfahrt Richtung Wiesbaden Erbenheim.

Photo: Bernd Kittendorf (info@bernd-kittendorf.de)
Homepage: www.bernd-kittendorf.de




Bahnhof Wolfenbüttel

Signal im Bahnhof Wolfenbüttel, aufgenommen am 24. August 2007.

Photo: Bernd Kittendorf (info@bernd-kittendorf.de)
Homepage: www.bernd-kittendorf.de




Bahnhof Zeitz

Einfahrt in den Bahnhof von Zeitz (Strecke Gera - Leipzig) aus Süden kommend gesehen am 11. August 2004.

Photo: Bernd Kittendorf (info@bernd-kittendorf.de)
Homepage: www.bernd-kittendorf.de




Bahnhof Zeitz

Formsignale an der nördlichen Ausfahrt aus dem Bahnhof Zeitz am 11. August 2004.

Photo: Bernd Kittendorf (info@bernd-kittendorf.de)
Homepage: www.bernd-kittendorf.de




Signal im Bahnhof von Cuxhaven (DE), Mai 2005

Photo: Peter Bottenberg pjotr_ivanich2000@yahoo.com




DB Signals at Dresden-Neustadt.
Looking towards Dresden Hauptbahnhof on Thursday May 8th, 2003, the signals are cleared for IC2240 (06:04 Magdeburg-Dresden) to proceed. The nose of the Steuerwagen is seen just to the left of the cyclists.

Photo by Michael Taylor, Hamilton, Ontario, Canada. (michael@einbahn.org)

Website www.einbahn.org




Unterwegs im IC 504 Basel - Köln. Alte Signale in Freiburg (Brsg) HBF.
Old signals in Freiburg (Brsg) HBF. Photo shot from IC 504 Basel - Cologne.

July 98

Photo and scan: A. Senn; http://www.senn.ch




Unterwegs im IC 504 Basel - Köln. Alte Signale in Freiburg (Brsg) HBF.
Old signals in Freiburg (Brsg) HBF. Photo shot from IC 504 Basel - Cologne.

July 98

Photo and scan: A. Senn; http://www.senn.ch




Friedrichshafen Stadtbahnhof
13. Oktober 1994

Foto: Frank Bruchertseifer (bm482366@muenchen.org)




1 March 1997, freight yard: Karlsruhe Gbf, Germany
A German semaphore main signal in combination with a semaphore approach signal. The main signal is the red/white one, the approach signal is the yellow/white one in front (and it of course relates to the next signal, which isn't in the picture). Both signals are of the three-aspect variety (proceed/proceed at restricted speed/stop) and show "stop"/"stop at next signal" here.

1. März 1997, Bf. Karlsruhe Gbf, Deutschland
Ein deutsches Formhauptsignal in Kombination mit einem Formvorsignal. Beide Signale sind dreibegriffig und zeigen hier "Halt"/"Halt erwarten".

Photo by Sven Manias (sven.manias@gmx.de)




A german semaphore.

Photo by Sven Herzfeld (s.herzfeld@maschsee.han.de)




A main signal and a distant signal of the semaphore system at the left track in Aachen Rothe-Erde. These semaphores were newly(!) errected in march 2001 to allow bidirectional operation to Stolberg. They are no more marked as invalid, but note that the distant signal has no post plate. I'm not shure if bidirectional operation is already in use by now. In order not to be covered by the roof, the signals were placed on the left. In the background the mechanical signalbox can be seen.

Digital photo by Christoph Schmitz




Zwergformsignal mit Wartesignal (Ra 11) und Stellwerk in Herzberg (Harz) am 31. August 1996.

Photo by: Holger Metschulat <homer@rt.e-technik.th-darmstadt.de>




A main signal and a distant signal of the semaphore system showing Hp0 (stop) and Vr0 (expect stop) in Aachen Rothe-Erde on 13 July 2001. D 423 (Oostende-Cologne) has just passed. Note that the distant signal is at reduced distance to the next main signal, for that a triangle is placed on it's post plate.

Digital photo by Christoph Schmitz




A main signal and a distant signal of the semaphore system showing Hp1 (proceed) and Vr0 (expect stop) in Aachen Rothe-Erde on 13 July 2001.

Digital photo by Christoph Schmitz




A main signal and a distant signal of the semaphore system showing Hp1 (proceed) and Vr1 (expect proceed) in Aachen Rothe-Erde on 13 July 2001.

Digital photo by Christoph Schmitz




While Dresden Hbf has new "Ks" light signals since 2000, Dresden-Neustadt still has the old semaphore signals like many decades ago. The signal in front is showing Hp2 (proceed at 40 km/h), the signals in the background show Hp0 (stop). Dresden-Neustadt, 2000-11-16.

Photo: tobias b köhler




This combination of semaphore signal and water crane was a common sight in German stations a long time ago, but is now becoming increasingly rare. In Dresden-Neustadt you can still see it. The signal is showing Hp0 (stop), the orange triangle with the "1" signifies a 10 km/h speed restriction in the track straight ahead (after the next turnout). The water crane is still functional and regularly used for special steam trains. Dresden-Neustadt, 2000-11-16.

Photo: tobias b köhler




Low semaphore signal in Dresden-Neustadt. The petroleum lights have been replaced by LED clusters. December 2000.

Photo: tobias b köhler




The semaphore signals U (right) and V (left) at the station Rothe Erde in Aachen seen from the platform on 1 May 2007. They are intermediate signals, placed between the entrance signals (which also server as exit signals of Aachen Hbf in this case) and the exit signals in the direction towards Cologne. Track 2 on the left is the through track for trains towards Cologne. The right track (probably known as track 3) is rarely used by train movements normally, it is predominantly used by shunting movements running between Rothe Erde and Hbf. During the next months this track should gain a lot of passenger train movements, as the refurbishment of the island platform will force trains towards Cologne to use a temporary platform at this track. Unlike V, the signal U has no distant signal next to it to announce the exit signal. Also I think that it can just show Hp2 (proceed with restriction to 40 km/h), but not Hp1 (proceed without speed restriction). Thus using this track ought slow down operations. Note that the shunting signal next to the signal U is set to Sh1 (clear), although no shunting movement was about to pass by. This is sometimes to be observed at mechanical signalboxes, where the shunting signals do not change back to Sh0 (stop) automatically when the shunting movement has passed. These semaphores will disappear in some months, the new cable channels already announce the construction of a new electronic signalbox.

Digital photo by Christoph Schmitz (christoph.schmitz2@post.rwth-aachen.de)




A main signal of the semaphore system seen at Heimbach (Eifel) on 26 September 2002. Please note that an M board is attached at the bottom, which means that the signal may be passed with a verbal permission of the signalman when it shows stop. The signal is at the dead end of the station, so it is normally only passed by shunting movements. Also I think it is not possible to set this semaphore to clear, as all signals normally needed for train movements on that line are new light signals.

Digital photo by Christoph Schmitz




Formeinfahrsignale des Bahnhofes Zinnowitz (Usedom), beide auf Hf2 (DR) bzw. Hp2 (DB).

Photo by: Holger Metschulat <homer@rt.e-technik.th-darmstadt.de>




Mechanical signal of Bavarian type. Bahnpark Augsburg, 2016-06-05.

tobias b köhler




Süddeutsches Eisenbahnmuseum Heilbronn, entrance
Semaphore signal 'Vr 0' in front of the South German Railway Museum Heilbronn. The museum has about 80 exhibits (wagons and locomotives). On the site is a locomotive roundhouse with a working turntable, as well as a large wagon shed. Steam and diesel engines can be serviced and looked after. Photo taken Monday 29 September 2014.

Photo: Steffen Mokosch (Steffen.Mokosch@web.de)




Bahnhof Annweiler am Trifels

Stellwerk und Ausfahrtsignale (noch Formsignale) des Bahnhofs Annweiler am Trifels an der Strecke von Landau (Pfalz) Hauptbahnhof nach Pirmasens Hauptbahnhof am 28. April 2007. Blickrichtung ist Landau.

Photo: Claudia Wolf (info@claudia-blondie-wolf.de)
Homepage: www.claudia-blondie-wolf.de




Landau (Pfalz) Hauptbahnhof

Formsignale in Landau (Pfalz) Hauptbahnhof, aufgenommen am 09. April 2010.

Photo: Bernd Kittendorf (info@bernd-kittendorf.de)
Homepage: www.bernd-kittendorf.de




Bahnhof Kandel

Formsignale an der Ausfahrt Richtung Wörth (Rhein) im Bahnhof Kandel, aufgenommen am 09. April 2010.

Photo: Bernd Kittendorf (info@bernd-kittendorf.de)
Homepage: www.bernd-kittendorf.de




Bahnhof Rüsselsheim

Formsignale und Stellwerk im Bahnhof Rüsselsheim, aufgenommen am 11. April 1997.

Photo: Detlef Kettner, Scan: Bernd Kittendorf (info@bernd-kittendorf.de)
Homepage: www.bernd-kittendorf.de




Bahnhof Wörth (Rhein)

Formsignale im Bahnhof Wörth (Rhein), aufgenommen am 09. April 2010.

Photo: Claudia Wolf (info@claudia-blondie-wolf.de)
Homepage: www.claudia-blondie-wolf.de
