| 91 80 6193 902-4, Vectron MS demonstrator owned by Siemens, equipped for 1.5 and 3 kV DC, 15 kV 16.7 Hz and 25 kV 16.7 Hz. Maximum power 6400 kW, maximum speed 160 to 200 km/h, tractive effort 300 kN, braking effort 150 to 240 kN, dynamic brake 2600 kW, wheel arrangement Bo'Bo', track gauge 1435 to 1676 mm, length 18980 mm, width 3012 mm, height 4248 mm, bogie distance 9500 mm, bogie wheelbase 3000 mm, wheel diameter 1250 mm, weight approx. 87 t, clearance gauge UIC 505-1. InnoTrans, Berlin, September 2010. |
| 91 80 6193 902-4, Vectron MS demonstrator owned by Siemens. As you can see here, the roof is fixed with screws. InnoTrans, Berlin, September 2010. |
| 91 80 6193 902-4, Vectron MS demonstrator owned by Siemens. For this version the driving console had to be extended, the empty square to the right can hold an analog manometer where required. InnoTrans, Berlin, September 2010. |
| 91 80 6193 902-4, Vectron MS demonstrator owned by Siemens. Back of the cab. InnoTrans, Berlin, September 2010. |
| 91 80 6193 902-4, Vectron MS demonstrator owned by Siemens. Interior. InnoTrans, Berlin, September 2010. |
