Weichenlaterne mit Zusatzfunktion als Wegweiser. Besonders der Hinweis ganz links wird schon so manche Arbeitsunfähigkeit verhindert haben. Oberhausen-Osterfeld am 17. November 2002.

Turnout-signal with additional feature as finger-post. From right to left: New York 8233 km, Moskau 7856 km, Turkey 140m behind the corner (many inhabitants of OB-Osterfeld are immigrants) and a very impotant hint: canteen only 82m. Oberhausen-Osterfeld on 17th of November 2002.

Photo by Arnim v. Herff (arnimvherff@uni-duisburg.de)




15 February 2001, freight yard: Karlsruhe Gbf, Germany
A turnout signal, indicating the position of the turnout.

15. Februar 2001, Bf. Karlsruhe Gbf, Deutschland
Weichensignal ("Weichenlaterne"), dient zur Anzeige der Weichenstellung.

Photo by Sven Manias (sven.manias@gmx.de)




15 February 2001, freight yard: Karlsruhe Gbf, Germany
Close-up of turnout signal.

15. Februar 2001, Bf. Karlsruhe Gbf, Deutschland
Nahaufnahme des Weichensignals. Der Kasten trägt die Aufschrift "A. Sartorius, Wuppertal, 1982".

Photo by Sven Manias (sven.manias@gmx.de)




Weichenstellhebel mit Schloss bei Marienburg. 19.09.2003

Photo taken by Tobias Meyer, ers@bf-vln.de




Eine ungewöhnliche Weiche im Karlsruher Rheinhafen.

Fotografiert von Michael Kauffmann mailto:MK@koben.DE




Eine ungewöhnliche Weiche im Karlsruher Rheinhafen.

Fotografiert von Michael Kauffmann mailto:MK@koben.DE




Rückfallweiche in Miedelsbach (WEG Strecke Schorndorf-Rudersberg)

Photo and scanned by Tobias Urban (tobias.urban@t-online.de)




Deutsche Bahn, Germany, Leipzig-Eilenburg railway line.
Near Jesewitz station, June 2004.

Photo by Stephan R. Schilling, cervin@matterhorn.strs.de




Two switches with movable frogs seen in Lövenich (on Cologne-Aachen) on 24 September 2001. In the foreground it is clearly visible that the frog closes the gap that is left open at switches with fixed frogs. Also note that there are no flangeways. At the switch in the background you can see that there are two distinct groups of actuators for the frog and for the tongues, and also two position indicators. The sleepers of the crossover track are divided in the middle and connected with something that seems to be elastic. Also the rails are fixed on the sleepers different in the switch area, compared to left track in the background. As far as I know, these switches have a turnout radius of 1200 m and can be passed with 100 km/h on the diverging route.

Digital photo by Christoph Schmitz




Two switches with movable frogs seen in Lövenich (on Cologne-Aachen) on 24 September 2001. This view shows the actuator group for the tongues of the first switch. Due to the temporary platform on the left, this switch is not yet equipped with position indicators. As far as I know, these switches have a turnout radius of 1200 m and can be passed with 100 km/h on the diverging route.

Digital photo by Christoph Schmitz




A double-slip switch under construction seen in Sindorf on the upgraded line Cologne-Düren (ABS 4) on 10 October 2001. The western half is already visible, at the left end is the center with the flangeways for the crossing tracks. The western frog is on the right in front of the catenary mast. Apart from this parts and the sleepers, only the outer rails for the diverging routes are by now assembled. The excavator is about to lift one of the tongues into position.

Digital photo by Christoph Schmitz




A double-slip switch under construction seen in Sindorf on the upgraded line Cologne-Düren (ABS 4) on 10 October 2001. The outer rails are for the diverging routes. Between them are the crossing tracks with the flangeways, one of the tongues was already attached to them. Another tongue lies in the foreground. Between the crossing rails the inner rails for the diverging routes will be installed, their fixtures are visible.

Digital photo by Christoph Schmitz




On 11 October 2001 the double-slip switch in Sindorf on the upgraded line Cologne-Düren (ABS 4) seems to be finished. The center with the flangeways for the crossing tracks is more or less in front of the catenary mast next to the switch. Towards the ends are the sections with the tongues and then the frogs with their flangeways.

Digital photo by Christoph Schmitz




The center of the finished double-slip switch seen in Sindorf on the upgraded line Cologne-Düren (ABS 4) on 11 October 2001. On each side four rails are coming from each end, they are (from inside to outside) one rail for the diverging tracks, then two rails for the crossing tracks and then one rail for the diverging track. The flangeways for the crossing tracks in the middle are passed by the rails of the diverging tracks both on the inside and on the outside. It is visible that the very inner rails continue as tongue, also does the second rail (counted from the outside). One of the inscriptions contains the term 1:9, as far as I know this is the angle of the switch.

Digital photo by Christoph Schmitz
