Oberleitungen über den hinteren Gleisen des Koblenzer Hauptbahnhofs.
Catenary at Koblenz mainstation.

Photo by Johannes Uhl, 03-01-04. eMail: johannes.uhl@epost.de




Bonn Station 23rd of May 2006.

(Photo & copyright by A. van Heyst, Netherlands, E-mail:A. van Heyst)




Oberleitungsmast in Forchheim, Oberfranken Aufgenommen am 09.02.2003

Alexander Kolb (al.kolb@web.de)




Alte Oberleitung im Bahnhof Forchheim (Oberfranken) Aufgenommen am 09.02.2003

Alexander Kolb (al.kolb@web.de)




Alte Oberleitung, Quertragewerk Aufgenommen am 09.02.2003

Alexander Kolb (al.kolb@web.de)




Tracks of the Höllentalbahn where they join the mainline near the south entrance of Freiburg (Breisgau) Hbf. This line is double track between Freiburg-Wiehre and Freiburg Hbf. Most of the overhead masts are still from pre-war times, with the characteristic curved brackets. Freiburg (Breisgau), 2003-12-29.

tobias b köhler




Auf der Hohenzollernbrücke. Köln, 16.05.2004

Photo: Szabó Zoltán (szaboz@freemail.hu)




Oberleitung in OB osterfeld

Foto Vincenzo 5.3.2007




A pair of catenary masts seen in Horrem (on Cologne-Aachen) on 16 December 2001. They have double brackets, as they are part of a five-field backbone span. This backbone span is also used as electrical seperation, so the brackets have to be insulated against eachother. This might be the reason for the unusual shape of the side clip, which has to keep some distance to the other contact wire. One bracket in the background still carries a pulley that was used to pull the contact wire into place.

Digital photo by Christoph Schmitz




Special catenary configuration above a double-slip switch with outside tongues (also known as "Baseler" type) seen at the western end of Köln Ehrenfeld Gbf on 31 July 2002. The two contact wires are spread to ensure that they cover every possible route the train (and the pantograph) can take.

Digital photo by Christoph Schmitz




Catenary works near Düren (on Cologne-Aachen) on 23 February 2003. The track was removed and built up new for a better alignment, so the brackets had to be replaced by longer ones. The lower arm (with the side clip) was just detached and will be brought down now. The train visible below spreads ballast onto the new track.

Digital photo by Christoph Schmitz




Catenary works near Düren (on Cologne-Aachen) on 23 February 2003. The track was removed and built up new for a better alignment, so the brackets had to be replaced by longer ones. The upper arm is being disassembled. Note that the catenary is not attached at this mast at this time, although the skylift holds it aside.

Digital photo by Christoph Schmitz




Catenary works near Düren (on Cologne-Aachen) on 23 February 2003. The track was removed and built up new for a better alignment, so the brackets had to be replaced by longer ones. The upper arm of the new bracket is being attached to the mast at the lower point. In the background is the ballast train.

Digital photo by Christoph Schmitz




Catenary works near Düren (on Cologne-Aachen) on 23 February 2003. The track was removed and built up new for a better alignment, so the brackets had to be replaced by longer ones. The upper arm of the new bracket is pulled up in order to be attached to the mast.

Digital photo by Christoph Schmitz




2 January 2002, Crailsheim, Germany
View of the catenary.

Digital photo by Klaus Föhl (klaus@foehl.net)




A bird nest on the top of a catenary mast, between various switches and wires. Seen on the highspeed line Cologne-Frankfurt between Siegburg station and the Siegauentunnel on 3 April 2003.

Digital photo by Christoph Schmitz




8 March 2002, Plochingen, Germany
Catenary detail in the east throat of Plochingen station. North of the railway line one may notice some characteristic houses designed by the artist and architect Hundertwasser.

Digital photo by Klaus Föhl (klaus@foehl.net)




Deutsche Bahn, Germany, Leipzig-Eilenburg railway line.
Near Jesewitz station, June 2004.

Photo by Stephan R. Schilling, cervin@matterhorn.strs.de




Deutsche Bundesbahn, Germany. Leipzig/ Thekla station.
Leipzig Thekla is an excellent place for watching freight trains, especially in the evening.
Watching the moon while waiting for the next train.

Photo by Stephan Rolf Schilling, June 2003.




Overhead wire circuit separator of DB type in Freiburg (Breisgau) Hbf. 2003-12-28.

tobias b köhler




RegioTram Kassel - Trennstelle 600 V / 15 kV

Trennstelle in der Oberleitung für den Systemwechsel der RegioTrams zwischen dem Netz der DB (15 kV Wechselstrom) und der Straßenbahn (600 V Gleichstrom) in Kassel Hauptbahnhof, aufgenommen am 28. Oktober 2007.

Photo: Bernd Kittendorf (info@bernd-kittendorf.de)
Homepage: www.bernd-kittendorf.de
