Steam U47.001 with historical coaches at Osoblaha station - 9.10.1998.

From 100 years celebration of narrow gauge railway Tremesna ve Slezsku - Osoblaha.

Photo by Jaroslav Jaburek Czech Rep. jaroslavjab@geocities.com




Steam U47.001 with historical coaches at Bohusov station - 9.10.1998.

From 100 years celebration of narrow gauge railway Tremesna ve Slezsku - Osoblaha.

Photo by Jaroslav Jaburek Czech Rep. jaroslavjab@geocities.com




Steam U47.001 with historical coaches depart from Bohusov station - 9.10.1998.

From 100 years celebration of narrow gauge railway Tremesna ve Slezsku - Osoblaha.

Photo by Jaroslav Jaburek Czech Rep. jaroslavjab@geocities.com




Steam train headed by class U47.001 on the line Liptan -Tremesna -- 11.10.1998.

From 100 years celebration of narrow gauge railway Tremesna ve Slezsku - Osoblaha.

Photo by Jaroslav Jaburek Czech Rep. jaroslavjab@geocities.com




Narrow gauge industrial locomotive No. 7 (who knows more?)

Railway museum Luzná u Rakovníka, 2007-06-19.

tobias b köhler




03 Oct 92;

Czech state railways' U47 001 near Alt Nagelberg on the ÖBB 760mm line from Gmünd to Litschau, on the left side the track of the branch to Heidenreichstein can be seen.

After overhaul in Ceske Velenice, on the other side of the border from Gmünd, this mallet type articulated engine came to the Waldviertel narrow gauge lines for some specials. After that it was transfered to the Jindrichuv Hradec network in the Czech Republic.

Photo and scan by Herbert Ortner (erlebnisbahn.ortner@gmx.net)




Krauss Linz 1518 of the Museum of Industrial Railways in Mladejov on tour.

The whole album about my journey to Czechia

Photo by Endre Barta (barta.endre@freemail.hu)
More pictures (mostly from Hungary): www.trains.hu




Krauss Linz 1518 of the Museum of Industrial Railways in Mladejov on tour.

The whole album about my journey to Czechia

Photo by Endre Barta (barta.endre@freemail.hu)
More pictures (mostly from Hungary): www.trains.hu




Krauss Linz 1518 of the Museum of Industrial Railways in Mladejov on tour.

The whole album about my journey to Czechia

Photo by Endre Barta (barta.endre@freemail.hu)
More pictures (mostly from Hungary): www.trains.hu




Krauss Linz 1518 of the Museum of Industrial Railways in Mladejov on tour.

The whole album about my journey to Czechia

Photo by Endre Barta (barta.endre@freemail.hu)
More pictures (mostly from Hungary): www.trains.hu




Nationales Technikmuseum Prag, XIVe Nr. 4, ex Stahlwerk Kladno, Prag, Juli 1996

Photo and scan by M.R.Koblischka (m.koblischka@mx.uni-saarland.de)




Národní technické muzeum, Praha, 2001-05-06

The tender locomotive of the type XIVe No.4 of track gauge 800 mm was made by the locomotive factory Krauss & Co. in Munich in 1884 with the serial number 1576. New boiler with the number 1616 was supplied in 1924 by the engineering joint-stock company, former Breitfeld, Danek i spol. in Slany. The locomotive was first used on the factory railway of Vojtesska Metallurgical Plant of the Prague Iron Works, later Steel Works Kladno. In 1981 to 1985 it was renovated and was exhibited at the EXPO'86 in Vancouver. Technical specification: axle arrangement B, duplex steam engine with external flat slide valves on cylinders and external valve gear Stephenson, hand lever brake with double-side braking of the second driving wheel set.

[text from http://www.ntm.cz/]

Photo: tobias b köhler




XIVe No.4 (800 mm narrow gauge, Krauss 1884) in the National Technical Museum in Prague. August 2019.

Photo by M.Koblischka




XIVe No.4 (800 mm narrow gauge, Krauss 1884) in the National Technical Museum in Prague. August 2019.
Rear view.

Photo by M.Koblischka




XIVe No.4 (800 mm narrow gauge, Krauss 1884) in the National Technical Museum in Prague. August 2019.
Cylinders.

Photo by M.Koblischka




XIVe No.4 (800 mm narrow gauge, Krauss 1884) in the National Technical Museum in Prague. August 2019.
Note the two narrow buffers.

Photo by M.Koblischka




XIVe No.4 (800 mm narrow gauge, Krauss 1884) in the National Technical Museum in Prague. August 2019.
Cab view.

Photo by M.Koblischka




XIVe No.4 (800 mm narrow gauge, Krauss 1884) in the National Technical Museum in Prague. August 2019.
Cab view.

Photo by M.Koblischka




XIVe No.4 (800 mm narrow gauge, Krauss 1884) in the National Technical Museum in Prague. August 2019.
Details of the Stephenson valve gear.

Photo by M.Koblischka




Narrow gague railway Jindrichuv Hradec - Nova Bystrice.
Formerly CSD, now JHMD.
Photo taken in the end station Nova Bystrice at 27.7.1997

Photo and scan by A. Kaldy (kaldy@albico.cz)




JHMD - 27.7.1997
Steam lokomotion U47.001 in railway station Nova Bystrice 27.7.1997.

Photo and scan by A. Kaldy (kaldy@albico.cz)




JHMD - 27.7.1997
Diesel train preceeding the steam one.

Photo and scan by A. Kaldy (kaldy@albico.cz)




JHMD - 27.7.1997
Station Hurky. Preparing for the return to Nova Bystrice.

Photo and scan by A. Kaldy (kaldy@albico.cz)




Steam engine U47 001 near Tremesna ve Slezsku in 11.10.1998.

Photo: Fodor Illés (illesf@kma.bme.hu)




Locomotive U47.001 (760mm) leaving Kunžak.

ing. Milan Černohorský (xcerno04@stud.fee.vutbr.cz)
