Transco narrow-gauge railway
of the NEAT building site in Sedrun. Diesel locomotive LK 3 with two
passenger cars in the tunnel. This is not the new Gotthard base tunnel,
but only an access tunnel to a vertical shaft which goes down 800 m to
the building site of the base tunnel.
Sedrun, 2003-02-10
Photo: Matthias Dingeldein |
|
Transco narrow-gauge railway
of the NEAT building site in Sedrun. Diesel locomotive LK 3 with two
passenger cars in the tunnel, and the great effect of reflecting stripes
in photo flashlight.
Sedrun, 2003-02-10
Photo: Reinhard Greulich |
|
Transco narrow-gauge railway
of the NEAT building site in Sedrun. Diesel locomotive LK 3.
Sedrun, 2003-02-10
Photo: Reinhard Greulich |
|
Transco narrow-gauge railway
of the NEAT building site in Sedrun. The impressive driving console of
the diesel locomotive LK 3.
Sedrun, 2003-02-10
Photo: Ralf Gunkel |
|
Transco narrow-gauge railway
of the NEAT building site in Sedrun. The "TGV" is used to move workers
in and out of the underground building site.
Sedrun, 2003-02-10
Photo: tobias b köhler |
|
Transco narrow-gauge railway
of the NEAT building site in Sedrun. The "TGV" is used to move workers
in and out of the underground building site. This tent-like station is near
the lower station of the funicular to the village and the temporary living
quarters of the workers.
Sedrun, 2003-02-10
Photo: Reinhard Greulich |
|
Transco narrow-gauge railway
of the NEAT building site in Sedrun. Looking through the access tunnel
(with two trains in sight).
Sedrun, 2003-02-10
Photo: Ralf Gunkel |
|
Transco narrow-gauge railway
of the NEAT building site in Sedrun. Looking through the access tunnel.
All machinery is brought to the building site through this tunnel, and
all material from the central building site is transported out to Sedrun
through here.
Sedrun, 2003-02-10
Photo: Hans-Jürgen Ramoschat |
|
Transco narrow-gauge railway
of the NEAT building site in Sedrun. Two-axle passenger car.
Sedrun, 2003-02-10
Photo: tobias b köhler |
|
Transco narrow-gauge railway
of the NEAT building site in Sedrun. This rotation dumper is used to
unload wagons with material from the tunnel (rocks and sand). Several
wagons are entirely turned upside down to unload them. The material is
then transported with conveyor belts to another station where it is
loaded on 1000 mm wagons which go down the mgb line to Disentis (and
further on to Chur on the RhB).
Sedrun, 2003-02-10
Photo: Ralf Gunkel |
|
Transco narrow-gauge railway
of the NEAT building site in Sedrun. This is where the shaft goes down to
the actual tunnel being built.
Sedrun, 2003-02-10
Photo: Ralf Gunkel |
|
Transco narrow-gauge railway
of the NEAT building site in Sedrun. A detail from the building site.
Sedrun, 2003-02-10
Photo: Hans-Jürgen Ramoschat |
|
Transco narrow-gauge railway
of the NEAT building site in Sedrun. The entrance - not to the new Gotthard
base tunnel (that's in Erstfeld), but to the access tunnel to a vertical
shaft which allows to build the tunnel from the middle (and will, once
the tunnel is finished, be used for ventilation and as an emergency exit
or even a regular station).
Sedrun, 2003-02-10
Photo: Hans-Jürgen Ramoschat |
|
Transco narrow-gauge railway
of the NEAT building site in Sedrun. The entrance seen from closer.
Sedrun, 2003-02-10
Photo: tobias b köhler |
