ONCF withdrawn electric locomotives

  Class NVR Number Axle Formula Number Year in Service Power [kW] Tractive Effort [kN] Max.Speed [km/h] Traction Type Voltage 1st class 2nd class
E 200
Bo'Bo' 7 1932 1210
75 E 3000V= --- ---
Mixed-traffic locomotives (ex-CFM), close to SNCF/Midi(F) Class 4200, later renumbered in E 621-627
E 501
Bo'Bo' 6 1926 680
90 E 3000V= --- ---
Passenger locomotives (ex-CFM), nrs. 501-506, close to SNCF/Midi(F) Class 4500. For mainline services on Fez-Marrakech
E 507
Bo'Bo' 4 1928 680
65 E 3000V= --- ---
Freight locomotives (ex-CFM), nrs. 507-510, close to SNCF/Midi(F) Class 4500. For phosphates on Oued Zem-Casablanca
E 600
Bo'Bo' 16 1929 1160
75/90 E 3000V= --- ---
Mixed-traffic locomotives (ex-CFM), close to SNCF/Midi(F) Class 4100
E 700
Bo'Bo' 14 1948 1220 152 80/115 E 3000V= --- ---
Low-power locomotives (ex-CFM), close to SNCF(F) Class 8100. For phosphates (Oued Zem-Casablanca) and other freighters
E 800
Co'Co' 7 1959 3200
90 E 3000V= --- ---
High-power freight locomotives (ex-CFM), close to SNCF(F) Class 7100. For phosphates (Oued Zem-Casablanca)
E 900
Co'Co' 7 1969 2427
75/125 E 3000V= --- ---
Universal locomotives by Alsthom, similar to SNCF(F) class 6500. For mainline services and freighters (Fez-Marrakech). Generator-van required in passenger service
E 1000
Co'Co' 23 1975 3000 412 125 E 3000V= --- ---
Freight locomotives by Kolmex (type 201Eg), similar to PKP(PL) class ET22 (11 sold back to Poland)
36000
Bo'Bo' 7
1997 5600 320 120 E 1.5+3kV=+25kV --- ---
Universal locomotives, asynchonous motors, triple voltage, "Astride" (with TBL), hired from SNCF Fret 2012-2016, nrs. 36001-06/08  (60 built)

ONCF withdrawn diesel locomotives

  Class NVR Number Axle Formula Number Year in Service Power [kW] Tractive Effort [kN] Max.Speed [km/h] Traction Type Voltage 1st class 2nd class
DA
A1A'A1A' 17 1947 1103
96 DE Diesel --- ---
Mainline diesel locomotives built by Cockerill (Baldwin license) in Belgium
DB
A1A'A1A' 7 1951 1103
120 DE Diesel --- ---
Similar to class DA, for passenger trains, 4 second-hand from Tunisia(1958), later rebuilt to 736kW
DC

6
552

DE Diesel --- ---
Second-hand locomotives from Compagnie du Mediterrannee bought in 1962

ONCF withdrawn trainsets and motor cars

  Class NVR Number Axle Formula Number Year in Service Power [kW] Tractive Effort [kN] Max.Speed [km/h] Traction Type Voltage 1st class 2nd class
ZAB 1000
EMU-1 10 1927 360
85 E 3000V=

Electric railcars (ex-CFM), close to SNCF(F) Z-4300, used on Casablanca-Rabat-Kenitra

Last update: 14-01-2017
